C-1000 Bariatric Ceiling Lift

Model / SKU: C-1000

Savaria Patient Care

The strongest lift in its class, rated at 1,000 lb for bariatric residents who exceed the capacity of lesser equipment, while preserving safety and dignity for patient and caregiver alike. A tandem dual-motor version can lift the torso and legs independently for precise, comfortable positioning.

  • 1,000 lb (454 kg) weight capacity
  • Tandem option adds a second motor on dual track so torso and legs can be lifted separately
  • Digital display with built-in diagnostics and a lift counter for maintenance compliance
  • Constant-charge capability plus emergency stop and emergency lowering
  • 1,000 lb scale available, with four carry bar designs and a Quick Release System for fast interchange
  • Rated for 17-20 full lifts per battery charge at maximum load
Get More Info

Call For Assistance

Every installation is different, so we quote each one properly. Give us a call and we'll talk you through the options.

Mon–Fri 8am–7pm · Sat 10am–5pm · Sun Noon–5pm

Specifications

Maximum load 1000 lb (454 kg)
Lift motor 24 VDC; traverse and H-frame traverse motors 24 VDC (optional)
Charger Input 120 VAC 1.0 A; output 24 VDC 1.5 A
Batteries 24 VDC (2 x 12 VDC) 5.0 Ah, sealed lead-acid
Lift case Flame-retardant ABS
Hand control Pneumatic
Lifting range Up to 96 in (2438 mm)
Lift weight 24.5 lb
Duty cycle 1 minute on, 9 minutes off
Rated performance 17-20 lifts at 1000 lb per full battery (24 in lifts mid-range)
Service life 22,500 cycles or 10 years, whichever comes first
Product codes 329100/329101 Manual Traverse (Docking/OMNI); 329150/329151 Power Traverse (Docking/OMNI); 329137 Power X/Y; 329126 Power Traverse w/ RTC
